DS-1127
DS
DS-1127
DMX512/ WDMX
Outdoor use
2.4inches TFT display operation
Carton or Flightcase
450W
1/2/7/11/15CH
4 kinds of curve dimmer
45° Beam Angle
13.5kg
Specifications:
•Rated Voltage:AC100V~240V 50-60HZ
•Rated Power:450W
•LED Qty:8x50W LED
•LED driver current:3A
•Color temperature:2700K±200(~1200K tungsten lamp)
•Beam angle:45°
•IP Class: IP65
•5 kinds DMX mode:1/2/7/11/15/CH
•Packing Size:585x220x425mm
•N.W:15kg G.W:18kg
Product Features
•DMX input:3-pin Seetronic J3F2C-W
•DMX output:3-pin Seetronic K3F2C-W
•Power connect:Seetronic powerCON IN (SAC3MPX) / OUT (SAC3FPX)
•Setting and addressing:RDM
•Software update :Update via DMX link
•3 kinds of control mode :DMX512、wireless DMX、Master-slave
•2.4G wireless DMX control
•DMX function:dimmer 、strobe、tungsten effect 、Auto、dimmer curve selection、function setting
•Stand-alone-:Auto、Mater-slave、tungsten effect、static color setting、Auto
•Housing material :aluminium alloy
•Housing color:black
•2.4 inch TFT display
•High anti-interference four touch buttons
•Operating temperature:-20°C~+40°C
•5 kinds DMX mode :1/2/7/11/15CH
•Can simulate the tungsten lamp effect
•Dimmer :0-100% linear dimmer
•Dimmer mode :4 kinds mode
•Dimmer frequency selection:800/1200/2000/3600/25K Hz
•Strobe effect :Plus Random、Ramp up Random、Ramp down Random、Random strobe、
Strobe Break Effect, 5s…..1s、Strobe0-20Hz
Specifications:
•Rated Voltage:AC100V~240V 50-60HZ
•Rated Power:450W
•LED Qty:8x50W LED
•LED driver current:3A
•Color temperature:2700K±200(~1200K tungsten lamp)
•Beam angle:45°
•IP Class: IP65
•5 kinds DMX mode:1/2/7/11/15/CH
•Packing Size:585x220x425mm
•N.W:15kg G.W:18kg
Product Features
•DMX input:3-pin Seetronic J3F2C-W
•DMX output:3-pin Seetronic K3F2C-W
•Power connect:Seetronic powerCON IN (SAC3MPX) / OUT (SAC3FPX)
•Setting and addressing:RDM
•Software update :Update via DMX link
•3 kinds of control mode :DMX512、wireless DMX、Master-slave
•2.4G wireless DMX control
•DMX function:dimmer 、strobe、tungsten effect 、Auto、dimmer curve selection、function setting
•Stand-alone-:Auto、Mater-slave、tungsten effect、static color setting、Auto
•Housing material :aluminium alloy
•Housing color:black
•2.4 inch TFT display
•High anti-interference four touch buttons
•Operating temperature:-20°C~+40°C
•5 kinds DMX mode :1/2/7/11/15CH
•Can simulate the tungsten lamp effect
•Dimmer :0-100% linear dimmer
•Dimmer mode :4 kinds mode
•Dimmer frequency selection:800/1200/2000/3600/25K Hz
•Strobe effect :Plus Random、Ramp up Random、Ramp down Random、Random strobe、
Strobe Break Effect, 5s…..1s、Strobe0-20Hz
